MULTI - The chimney system for multi-appliance connection
Technical reliability for airtight building envelopes
Modern residential construction utilizes tightly sealed windows and mechanical ventilation systems, which can compromise the air supply of conventional heating appliances. The Schiedel MULTI air-flue system solves this challenge by supplying fresh combustion air directly from above the roof through an annular gap in the chimney shaft, operating completely independent of indoor room air.
- Counter-Flow Air Preheating: Incoming combustion air travels downward through the outer annular gap, absorbing heat from the warm inner ceramic exhaust tube. This counter-flow mechanism reduces thermal loss and enhances system operating efficiency.
- Separated Air & Gas Streams: The intake opening and flue outlet at the chimney head are physically separated by a specialized airflow plate, preventing flue gas recirculation.
- Independent Billing & Control: Enables multi-occupancy of up to four decentralized gas boilers per floor, allowing tenants individual heating control and direct consumption billing.
Quicklinks
Optimized room-sealed operation
Operates completely independent of indoor ambient air, eliminating draft issues caused by sealed building envelopes or mechanical air extractors.
Operates completely independent of indoor ambient air, eliminating draft issues caused by sealed building envelopes or mechanical air extractors.
Multi-appliance flexibility
Accommodates multiple room-sealed gas floor-heating units—including modern condensing appliances—on a single stack. Integrated connection adapters compensate for pipe alignment tolerances and structural sound transmission.
Accommodates multiple room-sealed gas floor-heating units—including modern condensing appliances—on a single stack. Integrated connection adapters compensate for pipe alignment tolerances and structural sound transmission.
High-performance ceramic core
Features thin-walled, profiled ceramic inner tubes with leak-tight plug-in connections. Tested to moisture resistance standards ($<2\,\text{g/hm}^2$) and fully resistant to acids and soot fires.
Features thin-walled, profiled ceramic inner tubes with leak-tight plug-in connections. Tested to moisture resistance standards ($<2\,\text{g/hm}^2$) and fully resistant to acids and soot fires.
Streamlined installation & prefabrication
Lightweight concrete casing blocks with internal corner channels allow structural reinforcement setups for tall roof clearances. Available with factory-assembled base components for rapid site execution.
Lightweight concrete casing blocks with internal corner channels allow structural reinforcement setups for tall roof clearances. Available with factory-assembled base components for rapid site execution.
Further interesting content
Find the right product for you!
Haven't found the right product yet? Use our online assistant to find the right product for your needs.
ABSOLUT – The Schiedel premium chimney
Still not right for your requirements? Find out more about our ABSOLUT - the premium chimney for all types of fireplaces.
UNI PLUS
The classic UNI PLUS insulated chimney has a three-shell structure with rear ventilation, insulation board and fireclay inner pipe.
Details & Services
Find out more about the details and services for the MULTI chimney and flue gas system, such as the structure, detailed technical data or suitable services. You also have the option of downloading flyers or brochures about the product.
The system structure
The double-skin MULTI air extraction system is mounted on an AVANT prefabricated base. This contains a ceramic cleaning door connection with inspection cover and pressure equalization opening, as well as the condensate drain. The front end is formed by the foot panel with integrated cleaning door. It is now possible to install a fireplace on each floor. The MULTI is crowned by a chimney head that closes off the ceramic system.
Technical data
| Basic data (dimensions, weight & co.) | |
Wall thickness per diameter (internal) |
6 - 8 mm |
| Application | |
Flue gas temperature (dry) |
≤ 200 °C |
Material (Inner liner) |
Isostatic Ceramic |
Material (Outer case) |
Lightweight concrete |
Thermal resistance by insulation thickness |
0,003 - 0,007 m²K/W |
| General product features | |
Operating |
Negative pressure (N), Positive pressure (P-H) |
Room sealed |
Yes |
Occupation |
Multi |
Suitable for passive house |
No |
Heating technology |
Condensing boiler technology, Low temperature technology |
